禾伸堂建立in-house功能陶瓷材料實驗室，擁有自制陶瓷材料配方技術，生產一系列積層陶瓷電容，其中包括標準品和客制品，以滿足市場多變需求。透過先進的工廠利用最新設備與科技，滿足多變的客制化商品需求。
禾伸堂工廠通過ISO 9001及14001認證，車用電容產品取得嚴格的IATF 16949認證，安規電容亦擁有許多國際安規認證。
為提供完整服務，在陶瓷電容領域我們也特別加強應用性之特定產品與技術如下：
1. 高壓低電容量產品線：HVC-X7R, NP0 (100V至10000V)
2. 中壓高電容量產品線：HVC-X7R, X7S, X6S, X6R (50V至100V, up to 1uF)
3. 低溫飄系數，low bias材料：X7P
4. SMD型UL60950/X2與Y2/X1安規認證電容
5. 軟端子技術積層陶瓷電容 (SuperTerm)
6. 高效能穩定供電High CV Class 1 (NP0/CoG)陶瓷電容
7. 堆棧式之積層陶瓷電容
MVC
Medium voltage for commercial and industrial applications, NP0 and X7R available with rated voltage from 100V to 630V, in size from 0603 to 2225.
HVC
High voltage for commercial and industrial applications, NP0 and X7R available with rated voltage from 1KV to 8KV, in size from 0603 to 2225.
NCC
General use, for decoupling circuits. NP0, X7R, X5R available with rated voltage ranging from 6.3V to 50V, in size 0201 to 1206 with capacitance from 0.5pF to 820nF.
HCC
High capacitance for smooth (DC to DC) and decoupling circuits. Available in X7R, X7S, X6S, X5R at 4.0V to 50V, in size from 0201 to 2220 with capacitance from 1uF to 220uF.
HCN
High capacitance for ADSL/xDSL application (replacement for film capacitor). NP0 available with rated voltage from 16V to 50V, in size from 0603 to 2225 with capacitance from 1nF to 120nF.
SCC
Safety capacitor for isolation and protection circuits (UL, EN class X1/Y2, and X2). Available in NP0 and X7R at AC 250V to AC 305V, in size 1808 to 2825 with capacitance from 2.0pF to 56nF.
Automotive Grade Capacitors
Suitable for harsh automotive environment with no additional qualification testing. AEC-Q200 certified, available in NP0 and X7R, at 16V to 1KV, in size 0805 to 2220 with capacitance ranging from 10pF to 10uF.
HCP
Competitive price compared to X7T dielectric, made to meet general requirement. X7P is available, rated voltage from 250V to 630V, in size from 1206 to 2220 with capacitance from 10nF to 680nF.
HCT
Made to meet general requirement. X7T is available, rated voltage from 250V to 630V, in size from 1206 to 1812 with capacitance from 10nF to 470nF.
